Lub teeb ncej
Yangzhou Goldsun Hnub Ci Zog Co., Ltd. : Koj Tus Kws Tshaj Lij Choj Lub Teeb Chaw Tsim Khoom hauv Suav teb
Goldsun Solar tau tsim nyob rau xyoo 2009. Peb tshwj xeeb hauv kev tsim khoom lag luam - qib hnub ci teeb pom kev zoo, sib txuas cov thev naus laus zis siab nrog cov qauv zoo. Nrog kev txawj ntse hauv kev teeb pom kev zoo thiab hnub ci thev naus laus zis, thiab cov ntaub ntawv pov thawj ntawm cov khoom siv txhim khu kev qha, peb pab OEM thiab cov neeg siv khoom hauv ntau dua 86 lub teb chaws thoob ntiaj teb.
Certified Quality Assurance
Peb cov khoom tau txais daim ntawv pov thawj thoob ntiaj teb xws li ISO, CE, thiab TUV.
Customizable
Peb muab cov teeb pom kev zoo hnub ci teeb pom kev zoo tsim nyog rau txoj kev hauv nroog, txoj kev loj, thiab cov chaw nyob deb nroog kom tau raws li qhov project tshwj xeeb.
Guaranteed Off-Grid Performance
Peb cov khoom muab lub teeb pom kev zoo 365 hnub hauv ib xyoos, ua kom tsis muaj kev cuam tshuam kev ua haujlwm yam tsis muaj kev cia siab rau hauv daim phiaj hluav taws xob.
Kev Pabcuam thiab Kev Pabcuam
Peb muab cov kev pabcuam kawg -rau- kawg, suav nrog ua ntej- kev sib tham txog kev muag khoom, kev pab txhawb nqa, thiab kev npaj daws teeb meem.
Lub teeb ncej yog cov qauv ntsug siv los txhawb kev teeb pom kev zoo, xws li teeb pom kev, teeb pom kev zoo, lossis teeb pom kev hauv cheeb tsam, ntawm qhov siab, muab qhov pom kev zoo rau txoj kev, txoj kev, chaw nres tsheb, chaw ua si, lossis lwm qhov chaw sab nraum zoov.
Specification
|
Ncej Qhov siab |
4M |
5M |
6M |
7M |
8M |
9M |
10M |
12-15M |
|
Dimensions(d/D) |
60mm / 140mm |
60mm / 150mm |
70mm / 150 hli |
70mm / 170 hli |
80mm / 180 hli |
80mm / 190 hli |
85mm / 200 hli |
90mm / 210 hli |
|
Ncej Thickness |
3.0mm ib |
3.0mm ib |
3.0mm ib |
3.25mm ib |
3.5mm ib |
3.75mm ib |
4.0mm ib |
4.5mm ib |
|
Ncej Flange |
260mm * 12mm |
260mm * 14mm |
280mm * 16mm |
300mm * 16mm |
320mm * 18mm |
350mm * 18mm |
400mm * 20mm |
450mm * 20mm |
|
Kev kho saum npoo |
Kub-dip Galvanized thiab Electrostatic Spraying, Rustproof, Anti-corrosion kev ua tau zoo Class II |
|||||||
|
Hmoov txheej |
Thickness of powder coating>100 um. |
|||||||
|
Ntshiab polyester yas hmoov txheej yog ruaj khov, thiab muaj zog adhesion & muaj zog ultraviolet rays kuj. |
||||||||
|
Zaj duab xis thickness yog ntau tshaj 100 um thiab muaj zog adhesion. Qhov saum npoo tsis tev tawm txawm tias cov hniav khawb (15 × 6 mm square). |
||||||||
|
Cua Resistance |
Raws li cov huab cua hauv cheeb tsam, kev tsim lub zog ntawm cov cua tsis kam yog siab dua lossis sib npaug li 150KM / H |
|||||||
|
Kub-Dip Galvanized |
Thickness of hot-galvanized>8 0 awm. |
|||||||
|
Kub Dip Sab hauv thiab sab nraud tiv thaiv- kev kho corrosion los ntawm kub dipping acid, raws li BS EN ISO1461 lossis GB / T13912-92 tus qauv |
||||||||
|
Tsim lub neej ntawm tus ncej yog ntau tshaj 25 xyoo, thiab galvanized nto yog du thiab nrog tib xim. Flake peeling tsis tau pom tom qab maul kuaj. |
||||||||
Nta
Multifunctional Tsim
Lub teeb ncej tuaj nyob rau hauv ntau yam tsim, xws li puag ncig, square, conical, los yog cov qauv zoo nkauj, ntxiv rau cov qauv vaj tsev hauv nroog, kev lag luam, lossis thaj chaw nyob.
Adjustable Qhov siab
Cov ncej teeb muaj nyob rau hauv ntau qhov siab, feem ntau ntawm 3 mus rau 20 meters, ua kom pom kev pom kev zoo raws li txoj kev dav, thaj tsam loj, lossis qhov yuav tsum tau ua.
Yooj yim Installation
Cov ncej teeb yog tsim los rau lub hauv paus mounting lossis ntsia liaj qhov rooj -down installation, kom ruaj khov thiab txo lub sij hawm tsim kho.
Customization Options
Siab Customizable
Txoj kev teeb ncej qhov siab tuaj yeem hloov kho los ntawm 3 meters mus rau 20 meters lossis siab dua, nyob ntawm txoj kev dav, thaj chaw teeb pom kev zoo, thiab chaw teeb tsa.
Khoom siv Customization
Cov kev xaiv muaj xws li kub-dip galvanized steel, aluminium alloy, thiab cov ntaub ntawv sib xyaw.
Zoo thiab tsim Customization
Muaj nyob rau hauv round, square, conical, los yog cov duab zoo nkauj.
Kev kho deg Customization
Txhawb kev pleev xim, hmoov txheej, galvanizing, lossis tiv thaiv- kev kho corrosion.
Teeb Lub taub hau thiab Mounting Interface Customization
Cov ncej ncej tuaj yeem tsim kom haum rau ntau yam khoom siv teeb pom kev zoo (LED teeb, hnub ci txoj kev teeb, dej nyab, thiab lwm yam), txhawb nqa ntau lub teeb lub taub hau mounting txoj kev.
Foundation thiab Installation Method Customization
Yuav tsim nrog lub hauv paus phaj kho los yog ntsia liaj qhov rooj kho kom tau raws li lub hauv paus txheej xwm thiab kev tsim kho.
Smart Function Customization
Muaj peev xwm ua ke cov hnub ci vaj huam sib luag, sensors, cov chaw taws teeb tswj, lub koob yees duab, lossis lub tshuab tswj ntse.
Daim ntawv pov thawj
FAQ
Raws li ib qho ntawm cov kws tshaj lij lub teeb ncej manufacturers thiab cov muag khoom nyob rau hauv Suav teb, peb tau tshwj xeeb los ntawm cov khoom zoo thiab cov nqi sib tw. Thov so assured mus ua lag luam wholesale lub teeb ncej ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Tiv tauj peb rau kev pabcuam customized.
